ADVA CFP112G/LR4/SM/LC 100G/112G CFP Transceiver 1061700655-01 SMF 10km LC Module

ADVA CFP112G/LR4/SM/LC 100G/112G CFP Transceiver | 1061700655-01 | 10km SMF LC Module

The ADVA CFP112G/LR4/SM/LC (1061700655-01) is a high-performance CFP transceiver designed for 100G/112G optical networking. Featuring a 1310nm LAN-WDM wavelength and support for up to 10km transmission over single-mode fiber (SMF), this module ensures reliable, long-reach connectivity compliant with 100GBASE-LR4 and OTU4 standards. With a robust hardware revision 1.01 and Class 1 laser safety, it is the ideal choice for data center interconnections, metro core networks, and high-density router port expansion.

Product Model

CFP112G/LR4/SM/LC

Brand

ADVA (Optical Networking)

Product Item Number

1061700655-01

Form Factor

CFP (Centum Form Factor Pluggable)

Data Rate

112G / 100G (Compatible with OTU4 / 100GBASE）

Standard

100GBASE-LR4, OTU4

Fiber Type

Single-Mode Fiber (SMF)

Transmission Distance

Up to 10 km

Wavelength

1310nm (LAN-WDM)

Connector

Duplex LC

Supply Voltage

3.3V single supply

Power Consumption

< 16 W

Operating Temperature

0°C ~ 70°C

Diagnostics

DDM/DOM (Digital Diagnostic Monitoring)

Safety & Compliance

Class 1 Laser Product (21CFR 1040.10)

Country of Origin

China

Product Highlights

· 100G/112G High-Speed Performance: Supports both 112G and 100G bandwidth standards for flexible network upgrades.

· 10km Long-Reach Transmission: Delivers stable 10 km connectivity over standard single-mode fiber (SMF) using 1310nm LAN-WDM technology.

· Telecom-Grade Reliability: Designed for ADVA’s optical networking platforms, ensuring 24/7 operational stability.

· Hot-Pluggable CFP Form Factor: Easy in-service replacement and maintenance without system downtime.

· Complete Compatibility: Fully compliant with IEEE 802.3ba (100GBASE-LR4) and OTU4 standards, ensuring interoperability with mainstream network equipment.

Typical Applications

·  Data Center Interconnection (DCI)
