Alcatel-Lucent 3FE54823BA I-010S-P GPON ONT SFP Module BVL3AV8BAA The Alcatel-Lucent I-010S-P is a compact, industrial-grade SFP (Small Form-factor Pluggable) packaged GPON ONU module. Designed for modern FTTH and enterprise fiber networking deployments, this hot-pluggable module fits standard SFP slots of switches, routers, firewalls, and media converters, delivering a fixed 1Gbps line-rate Gigabit Ethernet interface at the host side while supporting standard GPON 2.488 Gbps downstream and 1.244 Gbps upstream PON transmission. Fully compliant with ITU-T G.984/G.988, SFP MSA, SFF-8472, and TR-156 specifications, it features exceptionally stable optical performance. It is the ideal option for reliable fiber access networking and high-performance ISP bypass configurations.
Model / Product Code
I-010S-P
Wavelength
1490nm Rx / 1310nm Tx
Data Rate
2.488 Gbps / Upstream 1.244 Gbps
Max Transmission Distance
20km
Product Type
GPON ONT SFP Module (ONU Stick)
Standard
IEEE 802.3ae 10GBASE-ZR
Power Consumption
Low power layout (< 2W)
Operating Temperature
40°C to +80°C
Typical Applications
FTTH (Fiber to the Home) Subscriber Access
- Inserted into SFP-compatible high-performance home or business routers to serve as a managed GPON ONT. It allows tech enthusiasts and remote workers to bypass standalone ISP optical modems, eliminating redundant power bricks and reducing cabling clutter.
Enterprise / Campus Network Upgrade (FTTB/FTTO)
- Installed in access switches with SFP ports to migrate legacy point-to-point Ethernet to GPON point-to-multipoint architecture, saving fiber strands and equipment costs.
VoIP Gateway Integration
- Plugged into SFP-equipped VoIP gateways to provide PON uplink for voice and data services without requiring separate CPE or external power supplies.
GPON Lab Testing & OLT Interoperability
- Used in laboratory environments alongside Alcatel-Lucent 7302/7360 ISAM OLTs for GPON network validation, OMCI testing, and device provisioning trials.
Product Highlights
1.GPON Anywhere
- Instantly upgrade any standard Ethernet box (switches, wireless backhaul equipment, routers, or EADs) into a GPON-capable device by inserting this SFP module.
2.Standard Compliance
- Fully compliant with Full Service Access Network (FSAN) ITU-T G.984.2 specifications (Class B+), ensuring great compatibility with leading OLTs.
3.Asymmetric Data Rates
- Supports high-speed fiber line rates of 2.488 Gb/s Rx (downstream) and 1.244 Gb/s Tx (upstream).
4.Advanced Remote Management
- Supports ONU Management and Control Interface (OMCI) functions per ITU-T G.988, enabling seamless remote configuration and monitoring via unified access management systems.
5.Rich Operational Utilities
- Built-in support for Logical Identifier (LOID) authentication, PON link status notification, Dying Gasp notification for power loss alerts, and Internet Group Management Protocol (IGMP) multi-cast functions.
6.Industrial-Grade Durability
- Built to withstand harsh environments with an extended operational temperature range of -40°C to +80°C.
