Ciena 160-9104-900 10GBASE-ER SFP+ Transceiver 10G 40km 1550nm LC SMF
The Ciena 160-9104-900 (SFPP10GE) is a high-performance 10GBASE-ER SFP+ optical transceiver, factory-calibrated for Ciena network equipment. Operating at 1550 nm, it supports 10Gbps Ethernet transmission up to 40 km over single-mode fiber. It features a duplex LC connector, full DDM/DOM monitoring, and meets IEEE 802.3ae and SFP+ MSA standards, making it ideal for Ciena metro and core network deployments.
Ciena Part Number
160-9104-900
Product Model
10GBASE-ER SFP+
Transmission Distance
10km
Standards
IEEE 802.3ae, SFP+ MSA, Class 1 Laser
Transmit Power
-1.0 ~ +4.0 dBm
Receiver Sensitivity
-14.4 dBm
Operating Temperature
0°C ~ 70°C
Typical Applications - Ciena Router and Switch 10G Uplink Interfaces
- Metro Core and Aggregation Network 10G Long-Reach Links
- Telecom Service Provider OTN and IP/MPLS Backbone Deployments
- Enterprise Campus and Data Center 10G Inter-Cabinet Connections
- 10GBASE-ER Standard Compliant Network Upgrades
Product Highlights
1. High-Speed 10G Long-Reach Single-Mode Transmission - This is a 10GBASE-ER SFP+ transceiver designed for telecom-grade long-haul transmission.
- It delivers 10Gbps wire-speed transmission over standard single-mode fiber (SMF) at 1550nm wavelength, supporting a maximum reach of 40km.
- The duplex LC interface is optimized for use in Ciena’s optical transport platforms, making it ideal for metro and core network links requiring long reach and high reliability.
2. Standard SFP+ Package & Ciena Ecosystem Compatibility
- It uses the industry-standard SFP+ (Small Form-factor Pluggable Plus) package, which is compact, hot-swappable, and widely adopted in telecom and enterprise switches.
- As a Ciena-branded module, it is natively validated for use with Ciena’s optical transport and switching equipment (e.g., Ciena 5100, 6500 platforms).
- Hot-plug-and-play design allows for easy installation, replacement, and capacity expansion without disrupting network operations.
3. Reliable Performance & Compliance Certification
- Built-in Digital Optical Monitoring (DOM) allows real-time monitoring of key parameters including TX/RX optical power, module temperature, supply voltage, and laser bias current.
- Certified as a Class 1 Laser product under 21CFR(J) standards, meeting strict carrier-grade safety and performance requirements.
- Manufactured in China, it undergoes rigorous factory testing to ensure stable performance within the commercial temperature range.
