Ciena 180-2350-900 WL5N 100G-400G CFP2-DCO TYPE5.0 DWDM SMF Coherent Transceiver Tunable C-band

The Ciena 180-2350-900 WL5N is a high-performance 100G-400G CFP2-DCO coherent optical transceiver designed for flexible long-haul DWDM transmission. Featuring full C-band tunability, integrated digital coherent DSP, and multi-rate support up to 400G, this module is fully compliant with CFP2 MSA and Type 5.0 standards. Manufactured in Canada with carrier-grade reliability and full coherent diagnostics, it is ideal for metro core networks, 400G data center interconnections, and Ciena routing/transport platform deployments.

Model Number	WL5N 100G-400G TYPE 5.0 CFP2-DCO	Band	Ciena
Form Factor	CFP2-DCO	Data Rate	100Gbps - 400Gbps
Wavelength	C-band tunable (1530-1565nm)	Transmission Distance	Up to 80km+
Connector	Duplex LC	Fiber Type	Single-Mode Fiber (SMF)
Transmission Protocol	DWDM	Hot Pluggable	Yes
Diagnostics	Full Digital Coherent Monitoring, DDM/DOM	Country of Origin	Canada
Standards	CFP2 MSA, OIF-400ZR, IEEE 802.3cn, Type 5.0	Safety & Compliance	Class 1M Laser Product, CE, RoHS, IEC 60825-1
Power Consumption	<3.5W	Supply Voltage	3.3VDC

Typical Applications

100G/400G Metro/Regional Core Networks
400G Data Center Interconnection (DCI)
100G/400G DWDM Long-Haul Telecom Backbone
Ciena 6500/5400 Routing & Transport Platforms
5G Mid-Haul/Back-Haul Transport

Product Highlights

1. High-Bandwidth Coherent Transmission

Powered by Ciena WaveLogic 5 Nano (WL5n) coherent technology, supporting dynamic rate adjustment from 100G to 400G on a single module
Digital Coherent Optics (DCO) architecture with advanced DSP, enabling long-haul DWDM transmission over single-mode fiber (SMF)
Compatible with 50GHz and flexible grid spacing, supporting seamless brownfield/greenfield network upgrades

2. Industry-Standard CFP2 Form Factor

Hot-pluggable CFP2 Type 5.0 DCO package, compliant with industry MSA standards for high-density router/transport platform deployment
Low-power design, delivering industry-leading power efficiency for metro, long-haul and data center interconnect (DCI) applications
Integrated digital diagnostics (DOM) for real-time monitoring of optical performance, temperature, voltage and laser parameters

3. Enterprise-Grade Reliability & Interoperability

Ciena-certified and rigorously tested for seamless interoperability with Ciena’s Waveserver, 6500, 8100 and other core networking hardware
Class 1 laser safety compliant (IEC 60825-1), meeting global safety standards, and RoHS 2/REACH environmental regulations
Industrial-grade component design, supporting wide operating temperature range for stable performance in harsh environments

4. Versatile Application & Scalability

Ideal for high-demand scenarios: long-haul backbone, metro packet transport, data center interconnection (DCI), 5G fronthaul/backhaul and cloud service provider networks
Future-proof 400G solution, enabling smooth migration from 100G/200G infrastructure without hardware replacement
Supports open ROADM and converged IP/Optical network architectures, reducing total cost of ownership (TCO)
