Ciena XCVR-CPRI02 CPRI 3-8 SFP+ 10G LR 10km 1310nm SMF LC Transceiver

Ciena XCVR-CPRI02 CPRI 3-8 SFP+ 10G LR 10km 1310nm SMF LC Transceiver

The Ciena XCVR-CPRI02 is a high-performance 10G CPRI 3-8 SFP+ optical transceiver, factory-calibrated for 4G/5G radio access network (RAN) front-haul applications. Operating at 1310 nm, it supports Common Public Radio Interface (CPRI) rates from 3 to 8 (up to 10Gbps) over single-mode fiber, with a reach of up to 10 km. Optimized for wireless base station and Remote Radio Head (RRH) connections, it features a duplex LC connector, full DDM/DOM monitoring, and meets CPRI and SFP+ MSA standards.

Ciena Part Number

XCVR-CPRI02

Band

  Ciena

Product Model

CPRI 3-8 10G SFP+

Form Factor

  SFP+

Wavelength

1310nm

Transmission Distance

10km

Connector

Duplex LC

Fiber Type

  SMF

Data Rate

10Gbps

Standards

CPRI, SFP+ MSA, Class 1 Laser

Supported Standards

CPRI 3-8 (up to 10Gbps)

Hot Swappable

  Support

Origin

China

Operating Temperature

0°C ~ 70°C

• 4G/5G Radio Base Station 10G CPRI Front-Haul Links
• RAN (Radio Access Network) Equipment Deployments
• Ciena and Third-Party SFP+ Compatible Network Devices
• 10G Short-Reach (10km) Fiber Connections Between Base Stations and Remote Radio Heads
• CPRI Standard Compliant 10G Wireless Network Upgrades

Product Highlights

• This is a CPRI (Common Public Radio Interface) SFP+ transceiver designed for 4G/5G radio access network fronthaul applications.
• It supports CPRI rates 3 to 8 (corresponding to up to 10Gbps) over standard G.652 single-mode fiber (SMF).
• Operating at 1310nm, it delivers stable 10Gbps transmission up to 10km, making it ideal for connecting baseband units (BBUs) to remote radio heads (RRHs).

• It uses the industry-standard SFP+ (10G Small Form-factor Pluggable Plus) package, widely adopted in wireless fronthaul equipment.
• As a Ciena-branded module, it is validated for use with Ciena’s radio access network and transport equipment.
• Hot-pluggable design allows for easy installation, replacement, and maintenance without disrupting network operations.

• Built-in Digital Optical Monitoring (DOM) allows real-time monitoring of key parameters including TX/RX optical power, module temperature, supply voltage, and laser bias current.
• Certified as an IEC Class 1 Laser product and CE compliant, meeting global carrier-grade safety and performance requirements.
• Manufactured in China, it undergoes rigorous factory testing to ensure stable performance in the commercial temperature range.
