Specifications

Item specifics

Condition: Used

Seller Notes: “Good condition Good Work! Tested”

Model: CFP2-100G-ER4

MPN: 10-3216-01

Country/Region of Manufacture: Japan

Brand: Cisco

Form Factor: CFP2

UPC: Does not apply

Item description from the seller

Cisco CFP2-100G-ER4, 10-3215-01,100G-40km-1310nm-SM-CFP2 IPU3BFTCAA

Table 1 provides cabling specifications for the Cisco CFP2 modules.

Table 1. CFP2 Port Fiber Specifications

Cisco CFP2	Wavelength (nm)	Fiber Type	Core Size (microns)	Modal Bandwidth (MHz-km)^***	Max Distance^*	Digital Optical Monitoring (DOM)
Cisco CFP2-100G-ER4	1310 band (LAN-WDM)	SMF	G.652	-	40 km^****	Yes

Specified at transmission wavelength.

Links longer than 30 km for the same link power budget are considered engineered links. Attenuation for such links needs to be less than the worst case specified for single-mode fiber.

Table 2 shows the main optical characteristics.

Table 2. CFP2 Port Fiber Specifications

Product	Type	Average Transmit Power (dBm)		Average Receive Power (dBm)		Transmit and Receive Wavelength
		Max	Min	Max	Min
Cisco CFP2-100G-ER4	100GBASE-ER4 1310 nm SMF	2.9 per lane	-2.9 per lane	4.5 per lane	-20.9 per lane	Four lanes: 1295.6 nm, 1300.1 nm, 1304.6 nm, and 1309.1 nm

Cisco CFP2-100G-ER4, 10-3215-01,100GBase-ER4 1310nm SMF 40km IPU3BFTCAA
