F5 OPT-0017-00 F5 Networks 10G F5-UPG-SFP+LR-R SFP+ 1310nm 10km Transceiver

$
F5

Product Features

Contact Us Email Now Chat Us With Whatsapp Chat Us With Skype Wechat: A13823619765
Specifications

Item specifics

Condition: Used
Seller Notes: “Grade A pulled, very good condition... 30days Warranty!!!”
Brand: F5 Networks
Type: 10Gig SFP+ 10G 10Gbase-LR 1310nm 10Km
Model: F5-UPG-SFP+LR-R
MPN: OPT-0017-00
Network Ports: SFP

UPC: Does not apply

Item description from the seller

One Genuine F5 Networks 10G F5-UPG-SFP+LR-R SFP+ 10GBASE-LR 10km 1310nm SFP+ Transceiver

P/N: OPT-0017-00


Specifications
NVIDIA/Mellanox InfiniBand Compatible
MMA4Z00-NS
Vendor Name
FS
Form Factor
Twin-port OSFP Finned Top
Max Data Rate
850Gbps (8x 106.25Gbps)
Wavelength
850nm
Max Cable Distance
30m@OM3/50m@OM4
Connector
Dual MTP/MPO-12 APC
Media
MMF
Transmitter Type
VCSEL
Receiver Type
PIN
TX Power
-4.6~4dBm
Minimum Receiver Power
-6.4dBm
Power Budget
1.8dB
Receiver Overload
4dBm
Max. Power Consumption
16W
Extinction Ratio
＞2.5dB
DDM/DOM
Supported
Commercial Temperature Range
0 to 70°C (32 to 158°F)
Modulation (Electrical)
8x100G-PAM4
Modulation (Optical)
Dual 4x100G-PAM4
CDR (Clock and Data Recovery)
TX & RX Built-in CDR
Inbuilt FEC
No
MTBF
6720167 Hours (@40°C, 60% CL)
4277043 Hours (@40°C, 90% CL)
Application
800G Ethernet
Protocols
OSFP MSA, CMIS 5.0, IEEE 802.3db, IEEE 802.3ck
Warranty
5 Years
