Finisar Genuine FTLC1154SDPL 100G QSFP28 LR4 OTU4 SMF 10km LC Optical Transceiver Module
The Finisar FTLC1154SDPL is a high-performance OTU4/100GBASE-LR4 QSFP28 optical transceiver, designed for long-reach enterprise and service provider networks. It operates at 13xx nm LAN-WDM wavelengths over standard single-mode fiber (SMF), supporting 100Gbps transmission up to 10 km with NRZ modulation. Equipped with an LC duplex connector, it is compliant with IEEE 802.3ba (100GBASE-LR4) and OTU4 standards, making it ideal for metro aggregation, data center interconnections, and long-reach backbone links. Factory-calibrated and tested, it delivers reliable 100G long-reach connectivity.
Model / Product Code
FTLC1154SDPL
Wavelength
LAN-WDM 13xx nm
DOM (Digital Monitoring)
Supported
Tx Power
-64.3 to +4.5 dBm
Rx Power
-10.6 to +4.5 dBm
Operating Temperature
0°C ~ 70°C
Product Highlights
1.10km Long-Reach 100G Carrier-Grade Solution
- Metro Aggregation and Long-Reach Enterprise Backbone Links Specifically engineered for metropolitan traffic aggregation, providing highly stable 100G core connections for large corporate backbones and institutional infrastructure.
2.Metro Data Center Interconnect (DCI) over Extended Distances - Optimized for linking high-capacity data centers and edge nodes across distributed facilities separated by up to 10 km.
3.Service Provider 100G Aggregation and Transport Networks - Perfect for telecom service providers looking for robust 100G traffic aggregation, transport loops, and high-performance core node clustering.
4.QSFP28 Port Switch/Router 100G Uplink Ports - Delivers native, carrier-grade 100G uplink capabilities for premium switches and core routers equipped with industry-standard QSFP28 slots.
5.High-Capacity Long-Reach Network Expansion Projects - Offers an efficient, unamplified scaling solution to instantly boost bandwidth and clear transmission bottlenecks over existing single-mode fiber infrastructure.
Typical Applications
1.Metro Aggregation and Long-Reach Enterprise Backbone Links
- Specifically engineered for metropolitan traffic aggregation, providing highly stable 100G core connections for large corporate backbones and institutional infrastructure.
2. Metro Data Center Interconnect (DCI) over Extended Distances - Optimized for linking high-capacity data centers and edge nodes across distributed facilities separated by up to 10 km.
3. Service Provider 100G Aggregation and Transport Networks - Perfect for telecom service providers looking for robust 100G traffic aggregation, transport loops, and high-performance core node clustering.
4. QSFP28 Port Switch/Router 100G Uplink Ports - Delivers native, carrier-grade 100G uplink capabilities for premium switches and core routers equipped with industry-standard QSFP28 slots.
5. High-Capacity Long-Reach Network Expansion Projects - Offers an efficient, unamplified scaling solution to instantly boost bandwidth and clear transmission bottlenecks over existing single-mode fiber infrastructure.
