OPTIC-WAY

Specifications

HP 455885-001 SFP+ 10Gb SR 850nm 300m MMF 10GBASE-SR Transceiver
The HP 455885-001 (SPS: 456096-001) is a factory-calibrated 10GBASE-SR SFP+ optical transceiver, designed for HP enterprise network equipment. Operating at 850 nm, it supports 10Gbps Ethernet transmission up to 300 meters over multi-mode fiber (MMF). This module features a duplex LC connector, full DDM/DOM monitoring, and is compliant with IEEE 802.3ae and SFP+ MSA standards.

HP Part Number

455885-001

Band

HP

Spare Part Number

456096-001

Form Factor

SFP+

Wavelength

8500nm

Transmission Distance

300m

Connector

Duplex LC

Fiber Type

MMF

Data Rate

10Gbps

Standards

IEEE 802.3ae, SFP+ MSA, Class 1 Laser

Diagnostics

Full DDM/DOM (SFF-8472)

Diagnostics

SupportFull DDM/DOM (SFF-8472)

Origin

Malaysia

Operating Temperature

0°C ~ 70°C

Typical Applications

HP/HPE Enterprise and Data Center Switch 10G Uplink Interfaces
10GBASE-SR Short-Reach Links for Data Center Top-of-Rack (ToR) and Leaf-Spine Networks
Campus and Building Backbone 10G Multi-Mode Fiber Deployments
High-Speed Server and Storage Network Connections
HP ProCurve/BladeSystem Series Network Equipment Upgrades

Product Highlights

1. 10GBASE-SR Short-Reach Transmission

This is an HP/HPE 10GBASE-SR SFP+ transceiver, designed for short-reach data center and enterprise applications.
It delivers 10Gbps line-rate transmission over multi-mode fiber (MMF) at 850nm wavelength, supporting a maximum reach of 300m (using OM3 fiber).
The duplex LC interface is optimized for use in HP/HPE ProLiant servers, switches, and storage systems.

2. Standard SFP+ Form Factor & HP Ecosystem Compatibility

It uses the industry-standard SFP+ (10G Small Form-factor Pluggable Plus) package, which is compact, hot-swappable, and widely adopted in HP/HPE equipment.
As an HP-branded module, it is validated for use with HPE ProLiant servers, BladeSystem enclosures, and HPE networking switches.
The hot-pluggable design allows for easy installation, replacement, and capacity expansion without disrupting network operations.

3. Reliable Performance & Compliance Certification

Built-in Digital Optical Monitoring (DOM) allows real-time monitoring of key parameters including TX/RX optical power, module temperature, supply voltage, and laser bias current.
Certified as a Class 1 Laser product under 21CFR1040.10 standards, and TUV Rheinland certified, meeting strict safety and performance requirements.
Manufactured in Malaysia, it undergoes rigorous factory testing to ensure stable performance in the commercial temperature range.

HP 455885-001 SFP+ 10Gb SR 850nm 300m 456096-001 MMF 10GBASE-SR Transceiver

Product Highlights
