Huawei 02311NTY 100GBASE-SR4 QSFP28 OM4 850nm 100m OMND10N13 MMF MPO Transceiver
Huawei 02311NTY OMND10N13 is a high-performance 100GBASE-SR4 QSFP28 optical transceiver, specifically designed for short-distance transmission up to 100 meters over OM4 multimode fiber. This module features an 850nm wavelength, 4×25G parallel channels, and optimized optical power budget, providing reliable 100G connectivity for high-density data center top-of-rack switches, server-to-switch links, and short-distance inter-rack connections. With MPO interface and full digital diagnostic monitoring (DDM/DOM), it is an ideal choice for high-speed 100G multimode deployment in enterprise and carrier-grade data center environments.
Huawei Part Number
02311NTY
Transmission Distance
Up to 100m
Fiber Type
Multi-Mode Fiber (MMF)
Operating Temperature
0°C ~ 70°C
Transmit Power
-8.4 dBm ~ +2.4 dBm
Receiver Sensitivity
-10.3 dBm
Typical Applications - 100G High-Density Data Center Top-of-Rack (ToR) Switch Deployments
- 100G Server-to-Switch and Inter-Rack Connections
- 100G Short-Reach Enterprise Campus Backbone
- High-Speed 100G Switch/ Router Port Expansion
- Carrier 100G Optical Access and Aggregation Networks
Product Highlights 1. 100G Short-Reach Multi-Mode Transmission
- 100GBASE-SR4 IEEE 802.3bm Compliant: Delivers 100Gbps aggregate bandwidth over OM4 multi-mode fiber (MMF)
- Parallel VCSEL Technology: Uses 4×25Gbps VCSEL channels at 850nm, supporting up to 100m (0.1km) reach on OM4 MMF
- MPO-12 Optical Interface: Designed for multi-fiber ribbon cables, ideal for high-density data center structured cabling
2. Industry-Standard QSFP28 Form Factor
- QSFP28 MSA-Compliant Package: Hot-pluggable, compact design for maximum port density in high-performance switches and routers
- Optimized Power Budget: Tx power range: -8.4 ~ +2.4dBm, Rx sensitivity: -10.3dBm, ensuring robust performance in short-reach links
- Huawei Certified: Seamlessly interoperable with Huawei CloudEngine series and other major vendor hardware
3. Advanced Network Management & Reliability
- Integrated Digital Optical Monitoring (DOM/DMI): Real-time monitoring of transmit power, receive power, temperature, voltage, and laser bias current
- Class 1 Laser Safety Compliant: Meets IEC 60825-1 and RoHS standards for global deployment
- Low-Power Design: Energy-efficient architecture minimizes operational costs and heat generation in high-density racks
