Mellanox MMS1C10-CM 100GBASE-PSM4 QSFP Transceiver 1310nm 500m SMF MPO

Mellanox MMS1C10-CM 100GBASE-PSM4 QSFP Transceiver 1310nm 500m SMF MPO

The Mellanox MMS1C10.CM is a high-performance 100GBASE-PSM4 QSFP optical transceiver designed for short-to-medium reach 500m/2km transmission over single-mode fiber. Delivering 100Gbps bandwidth via 4×25Gbps parallel lanes at 1310nm, this module is fully compliant with 100GBASE-PSM4 standard. Featuring a compact QSFP form factor, MPO-12 parallel interface, low power consumption, and full DDM/DOM diagnostics, it is ideal for high-density data center rack-to-rack interconnections, ToR switch connectivity, and Mellanox/NVIDIA InfiniBand/Ethernet network deployments.

Typical Applications

• 100G Intra-Data Center Rack-to-Rack Interconnection
• 100G Data Center ToR (Top of Rack) Switch Connectivity
• 100G Mellanox InfiniBand/Ethernet Network
• High-Density 100G Server/Storage Interconnection
• 100G Enterprise Campus Backbone

1. High-Speed 100G Short-to-Medium Reach Connectivity

• 100GBASE-PSM4 Compliant: Delivers 100Gbps aggregate bandwidth via 4 independent 25Gbps full-duplex channels, compliant with IEEE 802.3bm standard
• 1310nm Wavelength Optimization: Designed for single-mode fiber (SMF), supporting up to 500m transmission reach for data center intra-connect and high-performance computing (HPC) links
• 4x25G Breakout Capability: Enables flexible network architecture deployment, supporting smooth migration from 25G infrastructure to 100G backbone

2. Industry-Standard QSFP Form Factor & Interface

• Hot-Pluggable QSFP MSA Package: Compact design for maximum port density in high-density Mellanox InfiniBand/Ethernet switches, routers and servers
• MPO-12 Optical Interface: Fully compatible with standard MTP/MPO ribbon fiber cabling infrastructure, ideal for data center structured cabling
• Low-Power Design: Industry-leading power efficiency, reducing overall system power consumption and heat generation in high-density racks

3. Proactive Network Management & Enterprise-Grade Reliability

• Integrated Digital Optical Monitoring (DOM/DMI): Real-time monitoring of transmit power, receive power, temperature, voltage, and laser bias current for proactive fault detection and maintenance
• Mellanox Certified: Rigorously tested for seamless interoperability with Mellanox ConnectX adapters, Spectrum switches and InfiniBand EDR/HDR systems, plug-and-play deployment
• Class 1 Laser Safety Compliant: Meets IEC 60825-1 and 21CFR 1040.10 global safety standards, ensuring safe operation in all environments

4. Versatile Application & Scalability

• Ideal for HPC & Data Center: Perfect for high-performance computing clusters, data center top-of-rack (ToR) switching, storage area networks (SAN) and cloud infrastructure
• Future-Proof 100G Solution: Supports smooth network expansion and bandwidth upgrade, compatible with next-generation 200G/400G infrastructure migration
• Industrial-Grade Durability: Wide operating temperature range for stable performance in harsh data center environments
