Nokia 3FE71994AA CFP4 100GBASE-SR4 FTLC9141RENH-AB 850nm 100m/150m MMF MPO Transceiver

Nokia 3FE71994AA CFP4 100GBASE-SR4 FTLC9141RENH-AB 850nm 100m/150m MMF MPO Transceiver

The Nokia 3FE71994AA 01 is a high-performance 100GBASE-SR4 CFP4 optical transceiver designed for short-reach 100m/150m transmission over multi-mode fiber. Delivering 100Gbps bandwidth via 4×25Gbps parallel lanes at 850nm, this module is fully compliant with 100GBASE-SR4 standard. Featuring a compact CFP4 form factor, industrial temperature support, MPO-12 parallel interface, low power consumption, and full DDM/DOM diagnostics, it is ideal for high-density data center rack-to-rack interconnections, ToR switch connectivity, and 100G router/switch port expansion in Nokia network environments.

• 100G Intra-Data Center Rack-to-Rack Interconnection
• 100G Data Center ToR (Top of Rack) Switch Connectivity
• 100G High-Density Router/Switch Port Expansion
• 100G Server/Storage High-Speed Interconnection
• 100G Enterprise Campus Backbone

1. High-Speed 100G Short-Reach Connectivity

• Fully compliant with 100GBASE-SR4 IEEE 802.3bm standard, delivering 100Gbps aggregate bandwidth via 4 independent 25Gbps full-duplex channels
• 850nm VCSEL laser technology optimized for multi-mode fiber (MMF), supporting up to 100m transmission reach (OM4 MMF) for data center intra-connect and high-speed campus links
• Backward compatible with 4x25GBASE-SR, enabling flexible network architecture deployment and smooth migration from 25G/40G infrastructure

2. Compact CFP4 Form Factor & Interface

• Hot-pluggable, compact CFP4 MSA-compliant package (75% smaller than CFP, 50% smaller than CFP2) for maximum port density in high-density routers, switches and transport platforms
• MPO-12 optical interface, fully compatible with standard MTP/MPO ribbon fiber cabling infrastructure
• Extended temperature (Ctemp) design, supporting wider operating range for stable performance in harsh data center environments

3. Proactive Network Management & Enterprise-Grade Reliability

• Integrated Digital Optical Monitoring (DOM/DMI) for real-time monitoring of transmit power, receive power, temperature, voltage, and laser bias current, enabling proactive fault detection and maintenance
• Nokia-certified and rigorously tested for seamless interoperability with Nokia’s 7750 SR, 7250 IXR and other core networking hardware, plug-and-play deployment
• Class 1 laser safety compliant (IEC 60825-1, 21CFR 1040.10), meeting global safety standards, and RoHS 2/REACH environmental regulations for worldwide deployment

4. Versatile Application & Scalability

• Ideal for high-demand scenarios: data center top-of-rack (ToR) switching, storage area networks (SAN), high-performance computing (HPC) and enterprise campus networks
• Industrial-grade component design, supporting wide operating temperature range for stable performance in harsh data center environments
• Future-proof 100G solution, ideal for migrating from 40G networks to high-speed 100G backbone infrastructure
