Nokia 3HE04821BA CFP-100GBase-LR4 SMF 10km IPUIBU3DAA LOW POWER 0/70C
The Nokia 3HE04821BARA01 (Finisar FTLC1183RDNL-A5) CFP 100G LR4 optical transceiver is a high-performance solution for 100G Ethernet long-distance transmission. This module complies with IEEE 802.3ba 100GBase-LR4 standards, supporting up to 10 km transmission over single-mode fiber at 1310 nm. Featuring a hot-pluggable CFP form factor, low power consumption, and built-in DDM/DOM diagnostics, it is perfectly suited for telecom backbone networks, data center interconnections, and enterprise core routing environments.
Nokia Part Number
3HE04821BARA01
Finisar Part Number
FTLC1183RDNL-A5
Form Factor
CFP (Centum Form Factor Pluggable)
Data Rate
100Gb/s (103.1Gb/s aggregate)
Standard
100GBase-LR4 (IEEE 802.3ba)
Fiber Type
Single-Mode Fiber (SMF)
Transmission Distance
Up to 10 km
Wavelength
1310 nm LAN-WDM (4×25Gb/s DFB lasers)
Power Supply
3.3V single supply
Operating Temperature
0°C ~ 70°C
Diagnostics
DDM/DOM (Digital Diagnostic Monitoring)
Safety & Compliance
Class 1 Laser Safety, RoHS-6, CE, FCC
Country of Origin
Malaysia
Key Features
· Hot-Pluggable: Supports hot-swap for easy in-service maintenance and replacement.
· Low Power Design: Optimized for low power consumption, ideal for high-density data center and telecom deployments.
· Long-Haul Transmission: 1310nm LAN-WDM technology delivers stable 10 km transmission over single-mode fiber.
· 4-Channel Multiplexing: Leverages 4×25Gb/s LAN-WDM to carry 100G traffic over a single fiber pair.
· Real-Time Monitoring: Built-in DDM/DOM enables real-time monitoring of temperature, voltage, Tx/Rx optical power, and other critical parameters.
